Kraft Paper Roll Slitter Rewinder Machine Paper Roll Slitting Machine
paper roll slitter rewinder machine introduction
1. Paper weight: 80-600g; base diameter 1200mm; base width 1600mm; paper roll slitter rewinder machine cutting width is more than 30mm
2. paper roll sliitter rewinder machine Host motor for Shanghai strong speed (11kw), with adjustable speed function. Easy to adjust the production speed.
3. The motor speed can be adjusted by frequency conversion.
4. paper roll sliier rewinder machine Bending roll parting structure unique, completely avoid rewinding paper overlap. The radian of the bending roller can be adjusted at any time according to the paper.
paper roll sliiter rewinder machine Technical Parameters
| Base paper width | 1600(mm) |
| Diameter of base paper | 1200(mm) |
| Rewinding diameter | 1200(mm) |
| Slitting width | >35(mm) |
| Base paper weight | 80-600g |
| Number of cutters | 18pcs |
| Slitting speed | 1-300(m/min) |
| Speed control | Frequency control |
| Main power | 11kw |
| total weight | 4300kg |
| 控制系统Control System |
| Main motor | 11kw |
| Electrical components | Chint/Omron |
| Button/emergency stop | Siemens |
| Cylinder components | Airtac/Tianao |
| Hydraulic system | ENERGY |
| 配置装置Configuration device |
| Tension adjustment | Pneumatic brake |
| Paper loading method | Hydraulic Shaftless support |
| Unloading method | Hydraulic blanking |
| Winding method | Gas up outside the closed |
| Knife adjustment method | Manual |
| application tools | 1set |
paper roll slitter rewinder machineFeatures:
1. Simple, convenient operation and low price.
2. Fast speed.
our client
Companies rely on scientific andtechnological progress, the introduction ofhigh technology, is committed to newproduct development and technologyimprovement, and is equipped with perfectsales network and service system, theproducts have been sold all over thecountry, but also with domestic and foreigntrade import and export companycooperation, products have been exportedto South Asia, West Asia, Middle East, Africa, North and South America, Russia, Ukraine and other countries. At present, thecompany has set up its own foreign tradesales department, will further developforeign trade.
